接管尺寸 |
流量通径 mm |
流量系数CV |
流体压力范围（bar） |
介质温度 |
执行器 |
外形尺寸长×宽×高L×W×H |
重量KG |
订货型号 以下表中电压为220VAC 50/60HZ |
|
|
中性气体、液体 有杂质介质，高粘度介质 |
℃ |
电压AC |
扭矩N·M |
||||||
|
1 / 2 " |
15 |
4.5 |
0-25 |
0-120 |
220V |
50 |
79×210 |
5.0 |
DQ83SA20T320415 |
|
6.0 |
DQ83SA20T320415K |
||||||||
|
3/4" |
20 |
7.5 |
0-25 |
0-120 |
220V |
50 |
82×217 |
5.0 |
DQ83SA20T320520 |
|
6.0 |
DQ83SA20T320520K |
||||||||
|
1" |
25 |
12 |
0-25 |
0-120 |
220V |
50 |
90×227 |
5.5 |
DQ83SA20T320625 |
|
6.5 |
DQ83SA20T320625K |
||||||||
|
1 - 1/4 " |
35 |
24 |
0-25 |
0-120 |
220V |
80 |
112×230 |
6.5 |
DQ83SA20T320735 |
|
7.0 |
DQ83SA20T320735K |
||||||||
|
1 - 1/2 " |
40 |
29 |
0-25 |
0-120 |
220V |
100 |
120×263 |
8.0 |
DQ83SA20T320840 |
|
9.5 |
DQ83SA20T320840K |
||||||||
|
2" |
50 |
48 |
0-25 |
0-120 |
220V |
150 |
144×270 |
9.5 |
DQ83SA20T320950 |
|
11 |
DQ83SA20T320950K |
||||||||
|
2-1/2" |
65 |
52 |
0-25 |
0-120 |
220V |
300 |
176×337 |
21 |
DQ83SA20T322165 |
|
23 |
DQ83SA20T322165K |
||||||||
|
3" |
80 |
80 |
0-25 |
0-120 |
220V |
400 |
200×363 |
|
DQ83SA20T322380 |
|
|
DQ83SA20T322380K |
||||||||
|
4" |
100 |
128 |
0-25 |
0-120 |
220V |
600 |
227×411 |
|
DQ83SA20T3224100 |
|
|
DQ83SA20T3224100K |
||||||||
DQ83、DQ84选型方式：
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
||
|
DQ83型 |
阀体型式 |
电压 |
密封材料 |
阀体材质 |
连接方式 |
流量通径 |
其它选配 |
||
|
D |
Q |
83 |
S |
A20 |
T |
32 |
F |
15 |
K |
|
D=电动 |
Q=球阀 |
83=二位 |
S=三片式 |
A10=AC110V |
T=PTFE |
32=304不锈钢 |
04=1/2” |
15=15 |
K=流量调节(4-20mA信号或0-10VDC电 压可调) |
|
|
|
二通普 |
|
A20=AC220V |
P=PPL（高温） |
33=316不锈钢 |
05=3/4” |
20=20 |
|
|
|
|
通螺纹 |
|
D24=DC24V |
|
39=WCB铸钢 |
06=1” |
25=25 |
|
|
|
|
|
|
|
|
|
07=11/4” |
35=35 |
|
|
|
|
84=二位 |
|
|
|
|
08=11/2” |
40=40 |
|
|
|
|
二通高 |
|
|
|
|
09=2” |
50=50 |
|
|
|
|
温螺纹 |
|
|
|
|
21=21/2” |
65=65 |
|
|
|
|
|
|
|
|
|
23=3” |
80=80 |
|
|
|
|
|
|
|
|
|
24=4” |
100=100 |
|
|
|
|
|
|
|
|
|
|
125=125 |
|
|
|
|
|
|
|
|
|
|
150=150 |
|
|
|
|
|
|
|
|
|
|
200=200 |
|
