接管尺寸 G |
流量通径mm |
流量系数CV |
流体压力范围（bar） |
线 圈 |
功率 |
外形尺寸长×宽×高L×W×H |
重量KG |
订货型号 以下表中电压为220VAC 50/ 60HZ 材质以黄铜为例 |
||||
|
气体 |
液体 |
配置 |
AC 220V |
DC 24V |
||||||||
|
AC |
DC |
AC |
DC |
|||||||||
|
1/8” |
2.5 |
0.23 |
0-7 |
0-5 |
0-7 |
0-5 |
N |
13 |
8.5 |
40×27×67 |
0.35 |
AC11NA20N3101R3 |
|
3 |
0.3 |
0-5 |
0-4 |
0-5 |
0-4 |
N |
13 |
8.5 |
40×27×67 |
0.35 |
AC11NA20N310103 |
|
|
1/8” |
5 |
0.65 |
0-6 |
0-4 |
0-6 |
0-4 |
D |
20 |
20 |
43×30×79 |
0.46 |
AC11DA20N310105 |
|
6 |
0.8 |
0-4 |
0-2.5 |
0-4 |
0-2.5 |
D |
20 |
20 |
43×30×79 |
0.46 |
AC11DA20N310106 |
|
|
7.5 |
1.0 |
0-1.5 |
0-1 |
0-1.5 |
0-1 |
D |
20 |
20 |
43×30×79 |
0.45 |
AC11DA20N3101R8 |
|
|
1/4” |
2.5 |
0.23 |
0-7 |
0-5 |
0-7 |
0-5 |
N |
13 |
8.5 |
40×27×67 |
0.34 |
AC11NA20N3102R3 |
|
3 |
0.3 |
0-5 |
0-4 |
0-5 |
0-4 |
N |
13 |
8.5 |
40×27×67 |
0.34 |
AC11NA20N310203 |
|
|
1/4” |
5 |
0.65 |
0-6 |
0-4 |
0-6 |
0-4 |
D |
20 |
20 |
43×30×79 |
0.45 |
AC11DA20N310205 |
|
6 |
0.8 |
0-4 |
0-2.5 |
0-4 |
0-2.5 |
D |
20 |
20 |
43×30×79 |
0.45 |
AC11DA20N310206 |
|
|
7.5 |
1.0 |
0-1.5 |
0-1 |
0-1.5 |
0-1 |
D |
20 |
20 |
43×30×79 |
0.44 |
AC11DA20N3102R8 |
|
|
3/8” |
4 |
O.6 |
0-8 |
0-5 |
0-8 |
0-5 |
D |
20 |
20 |
53×26×87 |
0.6 |
AC11DA20N310304 |
|
5 |
0.65 |
0-6 |
0-4 |
0-6 |
0-4 |
D |
20 |
20 |
53×26×87 |
0.51 |
AC11DA20N310305 |
|
|
6 |
0.8 |
0-4 |
0-2.5 |
0-4 |
0-2.5 |
D |
20 |
20 |
53×26×87 |
0.51 |
AC11DA20N310306 |
|
|
7.5 |
1.0 |
0-15 |
0-1 |
0-15 |
0-1 |
D |
20 |
20 |
53×26×87 |
0.49 |
AC11DA20N3103R8 |
|
|
1/2” |
4 |
0.6 |
0-8 |
0-5 |
0-8 |
0-4 |
D |
20 |
20 |
53×26×87 |
0.48 |
AC11DA20N310404 |
|
5 |
0.65 |
0-6 |
0-4 |
0-6 |
0-5 |
D |
20 |
20 |
53×26×87 |
0.48 |
AC11DA20N310405 |
|
|
6 |
0.8 |
0-4 |
0-2.5 |
0-4 |
0-2.5 |
D |
20 |
20 |
53×26×87 |
0.46 |
AC11DA20N310406 |
|
|
7.5 |
1.0 |
0-1.5 |
0-1 |
0-1.5 |
0-1 |
D |
20 |
20 |
53×26×87 |
0.45 |
AC11DA20N3104R8 |
|
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
||
|
AC11型 |
线圈类型 |
电压 |
密封材料 |
阀体材质类型 |
连接方式 |
流量通 |
其它选配 |
||
|
A |
C |
11 |
D |
A20 |
N |
31 |
03 |
04 |
|
|
A= 直 动 |
C=常闭 |
11=系列号 |
D=塑封接
线盒式
N=塑封引线式
E=防爆型
M=低功耗
塑封型
|
A24=AC24V |
N=NBR丁腈橡胶 |
31=锻黄铜 |
01=1/8'' |
03=3.0 |
L=带灯接线盒 |
|
式 |
|
A36=AC36V |
|
|
02=1/4'' |
04=4.0 |
J=外置降温模块 |
||
|
|
|
A48=AC48V |
V=VITON氟橡胶 |
32=304不锈钢 |
03=3/8'' |
05=5.0 |
D=数字定时器 |
||
|
|
|
A10=AC110V |
|
浇铸 |
04=1/2'' |
06=6.0 |
N=美标NPT连接 |
||
|
|
|
A20=AC220V |
E=EPDM三元乙丙 |
33=316不锈钢 |
|
R3=2.5 |
其他螺纹可以定制 |
||
|
|
|
D12=DC12V |
|
浇铸 |
|
R8=7.5 |
|
||
|
|
|
D24=DC24V |
|
|
|
|
|
||
|
|
|
D36=DC36V |
|
|
|
|
|
||
