2/2 way Direct Acting solenoid valve

1、2/2-way Direct Acting、Open when energized，closed when de-energized
2、Automatic control of neutral gases and liquids
3、Small volume, large flow, simple structure
Control：Direct Acting
Body Material：Brass、Stainless steel 304(316 can be customized)
Maximum Pressure Resistance：20bar Maximum
Work Pressure：0~7bar
Ambient Temperature：0℃~65℃
Install：Flow as the arrow,Horizontal installation
Standard Voltage：AC：220V/50HZ 240/60HZ，
AC110V,DC24V, 12V……
Voltage fluctuations：+10%~-10%
Protection Level：IP65 100%ED
Seal：NBR(N)、EPDM(E)、VITON(V)
Electrical connection: Standard Connections（PG11)
Lead Wires（Optional）
Medium viscosity：20cst
Medium：neutral gases and liquids
Medium Temperature：NBR ( -10~+80℃)
                    EPDM (-30~+130℃)
                     VITON (-20~+150℃)

Down PDF

  • Model specification
  • Product structure





Pipe Size G





Orifice mm





CV

rate



Pressure（bar）

Coil Type



Power





Externsions Dimensions L×W×H





Weight

KG





Model Code

220VAC 50/60HZ

Air Gas

liquid



To confi gure



AC 220V



DC 24V

AC

DC

AC

DC



1/8”

2.5

0.23

0-7

0-5

0-7

0-5

N

13

8.5

40×27×67

0.35

AC11NA20N3101R3

3

0.3

0-5

0-4

0-5

0-4

N

13

8.5

40×27×67

0.35

AC11NA20N310103



1/8”

5

0.65

0-6

0-4

0-6

0-4

D

20

20

43×30×79

0.46

AC11DA20N310105

6

0.8

0-4

0-2.5

0-4

0-2.5

D

20

20

43×30×79

0.46

AC11DA20N310106

7.5

1.0

0-1.5

0-1

0-1.5

0-1

D

20

20

43×30×79

0.45

AC11DA20N3101R8



1/4”

2.5

0.23

0-7

0-5

0-7

0-5

N

13

8.5

40×27×67

0.34

AC11NA20N3102R3

3

0.3

0-5

0-4

0-5

0-4

N

13

8.5

40×27×67

0.34

AC11NA20N310203



1/4”

5

0.65

0-6

0-4

0-6

0-4

D

20

20

43×30×79

0.45

AC11DA20N310205

6

0.8

0-4

0-2.5

0-4

0-2.5

D

20

20

43×30×79

0.45

AC11DA20N310206

7.5

1.0

0-1.5

0-1

0-1.5

0-1

D

20

20

43×30×79

0.44

AC11DA20N3102R8





3/8”

4

O.6

0-8

0-5

0-8

0-5

D

20

20

53×26×87

0.6

AC11DA20N310304

5

0.65

0-6

0-4

0-6

0-4

D

20

20

53×26×87

0.51

AC11DA20N310305

6

0.8

0-4

0-2.5

0-4

0-2.5

D

20

20

53×26×87

0.51

AC11DA20N310306

7.5

1.0

0-15

0-1

0-15

0-1

D

20

20

53×26×87

0.49

AC11DA20N3103R8





1/2”

4

0.6

0-8

0-5

0-8

0-4

D

20

20

53×26×87

0.48

AC11DA20N310404

5

0.65

0-6

0-4

0-6

0-5

D

20

20

53×26×87

0.48

AC11DA20N310405

6

0.8

0-4

0-2.5

0-4

0-2.5

D

20

20

53×26×87

0.46

AC11DA20N310406

7.5

1.0

0-1.5

0-1

0-1.5

0-1

D

20

20

53×26×87

0.45

AC11DA20N3104R8


1

2

3

4

5

6

7

8



Ac11



Coil Types



Voltage



Seal Material



Body Material



Pipe Size



Orifice



Options

A

C

11

D

A20

N

31

03

04





A:

Direct Acting



C： Normally Closed



11:

Series



D=Din Standard Connections, Fully Encapsulated



A24=AC24V A36=AC36V A48=AC48V A10=AC110V A20=AC220V D12=DC12V D24=DC24V D36=DC36V



N=NBR



V=VITON



31=Forged

Brass

32=304



01=1/8''

02=1/4''

03=3/8''



03=3.0

04=4.0

05=5.0



L=Neon Lamp J=External cooling module D=Timer N=NPT

Other threads can be customized







N=Lead

Wires,





04=1/2''

06=6.0







Water-light, Fully

Encapsulated

E=EPDM

33=316



R3=2.5

R8=7.5







E=Explosion-















proof















M=Low















Power
